Note: Data may vary by configuration. See CONFIGURATION section.
| Cavity |
T-23A |
| Series |
3 |
| Capacity |
60 gpm240 L/min. |
| Maximum Operating Pressure |
5000 psi350 bar |
| Control Pilot Flow |
15 - 20 in³/min.0,25 - 0,33 L/min. |
| Pilot Control Cavity |
T-8AT-8A |
| Main stage leakage at 110 SUS (24 cSt) |
4 in³/min.@1000 psi65 cc/min.@70 bar |
| Response Time - Typical |
10 ms10 ms |
| Valve Hex Size |
1 1/4 in.31,8 mm |
| Valve Installation Torque |
150 - 160 lbf ft203 - 217 Nm |
| Model Weight |
1.60 lb0,70 kg |
| Seal kit - Cartridge |
Buna: 990023007 |
| Seal kit - Cartridge |
EPDM: 990023014 |
| Seal kit - Cartridge |
Polyurethane: 990023002 |
| Seal kit - Cartridge |
Viton: 990023006 |
