PRDLMDN Electro-proportional, direct-acting, pressure reducing/relieving valve with open transition

PRDLMDN Electro-proportional, direct-acting, pressure reducing/relieving valve with open transition

Price : $227.35
:
Add to Favorites
Add to My Wish List
Compare
Notify me when the price goes down
Notify me when it is in stock
Recommend
Write a comment
PRDL

Note: Data may vary by configuration. See CONFIGURATION section.
Cavity T-11A
Series 1
Capacity 5 gpm20 L/min.
Maximum Operating Pressure 5000 psi350 bar
Maximum Valve Leakage at 110 SUS (24 cSt) 20 in³/min.330 cc/min.
Adjustment - No. of CW Turns from Min. to Max. setting 55
Solenoid Tube Diameter .75 in.19 mm
Valve Hex Size 7/8 in.22,2 mm
Valve Installation Torque 30 - 35 lbf ft41 - 47 Nm
Adjustment Screw Internal Hex Size 5/32 in.4 mm
Locknut Hex Size 9/16 in.15 mm
Locknut Torque 80 - 90 lbf in.9 - 10 Nm
Model Weight (with coil) 1.20 lb0,55 kg
Seal kit - Cartridge Buna: 990511007
Seal kit - Cartridge Viton: 990511006
Seal and nut kit - Coil Viton: 990770006
Back to Top


PRDL
Low Flow Rate
0-150 lpm
