Note: Data may vary by configuration. See CONFIGURATION section.
| Cavity |
T-2A |
| Series |
2 |
| Capacity |
50 gpm200 L/min. |
| Maximum Operating Pressure |
5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) |
10 drops/min.0,7 cc/min. |
| Pilot Volume Displacement |
.07 in³1,1 cc |
| Pilot Passage into Valve |
.035 in.0,9 mm |
| Area Ratio, A3 to A1 |
1.8:11.8:1 |
| Area Ratio, A3 to A2 |
2.25:12.25:1 |
| Valve Hex Size |
1 1/8 in.28,6 mm |
| Valve Installation Torque |
45 - 50 lbf ft61 - 68 Nm |
| Seal kit - Cartridge |
Buna: 990202007 |
| Seal kit - Cartridge |
Polyurethane: 990002002 |
| Seal kit - Cartridge |
Viton: 990202006 |
