Note: Data may vary by configuration. See CONFIGURATION section.
| Cavity |
T-19A |
| Series |
4 |
| Capacity |
120 gpm480 L/min. |
| Maximum Operating Pressure |
5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) |
10 drops/min.@1000 psi0,7 cc/min.@70 bar |
| Pilot Volume Displacement |
.30 in³4,9 cc |
| Pilot Passage into Valve |
.09 in.2,3 mm |
| Area Ratio, A3 to A1 |
1.8:11.8:1 |
| Area Ratio, A3 to A2 |
2.25:12.25:1 |
| Valve Hex Size |
1 5/8 in.41,3 mm |
| Valve Installation Torque |
350 - 375 lbf ft474 - 508 Nm |
| Seal kit - Cartridge |
Buna: 990019007 |
| Seal kit - Cartridge |
EPDM: 990019014 |
| Seal kit - Cartridge |
Polyurethane: 990019002 |
| Seal kit - Cartridge |
Viton: 990019006 |
