Note: Data may vary by configuration. See CONFIGURATION section.
| Cavity |
T-11A |
| Series |
1 |
| Capacity |
6 gpm23 L/min. |
| Maximum Valve Leakage at 110 SUS (24 cSt) |
2 in³/min.@1000 psi30 cc/min.@70 bar |
| Manual Override Force Requirement |
5 lbs/1000 psi @ Port 133 N/100 bar @ Port 1 |
| Manual Override Stroke |
.10 in.2,5 mm |
| Solenoid Tube Diameter |
.75 in.19 mm |
| Valve Hex Size |
7/8 in.22,2 mm |
| Valve Installation Torque |
30 - 35 lbf ft41 - 47 Nm |
| Model Weight (with coil) |
1.10 lb0,50 kg |
| Seal kit - Cartridge |
Buna: 990411007 |
| Seal kit - Cartridge |
Viton: 990411006 |
| Seal and nut kit - Coil |
Viton: 990770006 |
