Note: Data may vary by configuration. See CONFIGURATION section.
| Cavity |
T-13A |
| Series |
1 |
| Capacity |
6 gpm23 L/min. |
| Maximum Operating Pressure |
5000 psi350 bar |
| Valve Hex Size |
7/8 in.22,2 mm |
| Valve Installation Torque |
30 - 35 lbf ft41 - 47 Nm |
| Adjustment Screw Internal Hex Size |
5/32 in.4 mm |
| Locknut Hex Size |
9/16 in.15 mm |
| Locknut Torque |
80 - 90 lbf in.9 - 10 Nm |
| Model Weight |
.30 lb0,15 kg |
| Seal kit - Cartridge |
Buna: 990010007 |
| Seal kit - Cartridge |
Polyurethane: 990010002 |
| Seal kit - Cartridge |
Viton: 990010006 |
