Note: Data may vary by configuration. See CONFIGURATION section.
| Cavity |
T-33A |
| Series |
3 |
| Capacity |
60 gpm240 L/min. |
| Maximum Operating Pressure |
5000 psi350 bar |
| Nominal Vent Flow |
35 in³/min.0,60 L/min. |
| Valve Hex Size |
1 1/4 in.31,8 mm |
| Valve Installation Torque |
150 - 160 lbf ft203 - 217 Nm |
| Model Weight |
4.40 lb2,00 kg |
| Seal kit - Cartridge |
Buna: 990033007 |
| Seal kit - Cartridge |
Polyurethane: 990033002 |
| Seal kit - Cartridge |
Viton: 990033006 |
