Note: Data may vary by configuration. See CONFIGURATION section.
| Cavity |
T-16A |
| Series |
3 |
| Capacity |
60 gpm240 L/min. |
| Maximum Operating Pressure |
5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) |
10 drops/min.@5000 psi0,7 cc/min.@350 bar |
| Pilot Control Cavity |
T-8AT-8A |
| Pilot Control Valve Installation Torque |
20 - 25 lbf ft27 - 33 Nm |
| Response Time - Typical |
see pilot control mssee pilot control ms |
| Valve Hex Size |
1 1/4 in.31,8 mm |
| Valve Installation Torque |
150 - 160 lbf ft203 - 217 Nm |
| Model Weight |
1.10 lb0,50 kg |
| Seal kit - Cartridge |
Buna: 990016007 |
| Seal kit - Cartridge |
Polyurethane: 990016002 |
| Seal kit - Cartridge |
Viton: 990016006 |
