Note: Data may vary by configuration. See CONFIGURATION section.
| Cavity |
T-8A |
| Series |
P |
| Capacity |
7 gpm28 L/min. |
| Maximum Operating Pressure |
5000 psi350 bar |
| Maximum Valve Leakage at 110 SUS (24 cSt) |
0.004 in³/min.@5000 psi0,07 cc/min.@350 bar |
| Viscosity Range |
35 - 2000 SUS2,8 - 380 cSt |
| Response Time - Typical |
50 ms50 ms |
| Switching Frequency |
15,000 max. cycles/hr15,000 max. cycles/hr |
| Valve Hex Size |
7/8 in.22,2 mm |
| Valve Installation Torque |
20 - 25 lbf ft27 - 33 Nm |
| Model Weight |
5.6 oz.159 grams |
| U.S. Patent # |
10,302,20110,302,201 |
| Seal kit - Cartridge |
Buna: 990608007 |
| Seal kit - Cartridge |
Viton: 990608006 |
| Seal and nut kit - Coil |
Viton: 990740006 |
